Key Features * Fast Correction rate and very high efficiency. * Works over wide input frequency range and no waverform distortion. * Specially designed high performance I.C. based control circuit for ultra high reliability. * Auto / Manual operation facility. * Stabilizers are subject to routine and type testes in accordance with latest BIS standards (BIS: 9815-94) * Unaffected by Load Power Factor. * Over voltage and under voltage indicators. * Output voltage adjustability provided on panel. * All components used are of reputed makes conforming to relevent BiS standards. * Easy accessibility from all four sides. * Plug-in type glass-epoxy control cards for easy on line serviceability.

Advantages Of ADP Servo Voltage Stabilizers

* Corrects voltage automatically and continuously. * Induction motors operate at high efficiency when supplied with constant Voltage. * Protects costly equipments from menace of High/ Low Voltage, thus cutting down the maintenance cost. * 100% depreciation as per Income Tax act. * Increased Productivity. * Low Production losses & better efficiency in plant. * Saves on diesel cost, as generator iS not required to run at High / Low input voltage. * Reduction in electricity bills up to the level of app. 15% (This depends on the input variation, loading and the number of working hours) * Easy accessibility from all four sides. * Reduces MDI and saves Power. * Increased Productivity.

Field Of Application * Information Technology and Call centers. * Computer and Micro-Processor Controlled Equipments. * Sophisticated research instruments used in Scientific, Medical, Agriculture, Educational and other Research institutions. * Complete Hospital and Nursing Homes * Medical Equipments, X-Ray Machines, E.C.G. Machines / Monitors, MRI, CT Scans etc. * Defence Installations, LPTs, HPTs, Broadcasting and Telecommunications. *  Lifts, Escalators and Elevators. * Central Air-Conditioning Plants, Processing Plant, Chemical Industries, Textile Industries. * Offset Printing Presses. Colour Scanners, Processors, Photographic, Photo Copiers and Packaging Industries. * Commercial Buildings and Complexes. * CNC Machines, Laser Machines and Moulding Machines etc.

Technical Specification * Capacity * Input Voltage * Output Voltage * Regulation * Supply Frequency * Efficiency * Effect of Load Power Factor * Wave form Distortion * Rate of Correction * Duty Cycle * Response Time * Cooling * Over Load Capability * No Load Losses * Suitability * Mounting * Earthing * Suitable for 3 Ph. unbalanced/balanced supply & unbalanced / balanced load. * Earthing Terminals Provided. * 1 KVA to 100 KVA (Single Phase) * 3 KVA to 300 KVA (Three Phase) * 160V - 260V, 140V - 270V (Single Phase) * 300V - 450V, 240V - 470V (Three Phase) * 220V / 230v / 240v Single Phase * 380V / 400V / 415V Three Phase * ± 1% or better. * 47 Hz - 53 Hz. * better than 97% * Nil *  Better than 20V / sec. in AIR cooled models. * Better than 36V / sec. in OIL cooled models. * 100% continuous. * Less than 100 ms. * Air / Oil as per requirement. * Upto 200% momentarily. * Less then 0.8% over entire range. * On Wheels Selection Guide Choosing the right KVA of a Servo Stabilizer a. KVA of Stabilizer = H.P. of lift * 3 b. KVA of Stabilizer = Tonnage of A.C. plant * 2 c. KVA of Stabilizer = H.P. for Resistive loads d. KVA of Stabilizer = H.P. or K.W./ Power factor for Reactive loads. Note : While precuring / installing servo stabilizer on mains, care should be taken and ensure that the capacity of servo voltage stabilizer is more than the maximum load connected / Can be operated through it at any time.
